siemens s7-1200 6es7223-1bl30-0xb0 digital-I/O

Specification: siemens s7-1200 6es7223-1bl30-0xb0 digital-I/O, siemens s7-1200 6es7223-1bl30-0xb0 digital-I/O Brand: siemens Product Model:  6es7223-1bl30-0xb0 Digital Inputs: Number of Digital Inputs: 8 inputs Input Type: 24V DC Input Current: 5 mA (Type 1) Input Delay (0.5 ms): < 0.1 ms Digital Outputs: Number of Digital Outputs: 8 outputs Output Type: Relay (mechanical) Output Voltage: 24V DC Output Current: 2 A per channel Total Output Current: 8 A (sum of all channels) Switching Frequency: 10 Hz (max) Contact Resistance: < 50 mΩ General Specifications: Module Supply Voltage: 24V DC (nominal) Power Consumption: 30 mA (from backplane bus) Isolation: Optically isolated between inputs, outputs, and the backplane bus Operating Temperature: 0 to 55°C (32 to 131°F) Storage Temperature: -40 to 70°C (-40 to 158°F) Dimensions (W x H x D): 40 x 125 x 120 mm Weight: Approx. 180 g     Click
